设计名称
手扶振动压路机的设计【说明书+CAD】
设计编号
JX1981
设计软件
AutoCAD,Word
包含内容
见右侧图片
说明字数
见下方截图
图纸数量
见右侧图片
推荐指数
较高
价格
价格优惠中
整理日期
2019-05-03
整理人
admin
设计简介
摘要:压力原理上,探讨了土中含水量,压路机的震动压实功能与土的级配组成对压实效果的影响。且进一步对振动压实原理做研究,振动压实类型及振动压路机的力学模型进行了研究。分析了振动对压实材料剪应力、抗剪强度的影响,结合各个因素来考虑设计手扶压路机结构,简要提出了对振动压路机参数的选择和提高压实效率的途径。
关键词:手扶压路机 振动压路机
Abstract: On the analysis of soil properties and and soil compaction performance, discusses on the basis of the soil moisture content, roller compaction function and soil graded composition on compaction effect. And further, the vibration compaction mechanism of vibration compaction type and mechanics model of vibratory rollers are studied. Analysis of the vibration compaction material shear stress, shear strength with the influence of the structure of vibratory roller, analyzed its mechanical properties, briefly proposed to the vibratory rollers parameter selection and improve the efficiency of the way compaction.

 目录
第一章  概述 1
1.1  选题目的与意义 1
1.2  设计题目及参数要求 1
第二章  压路机工作参数的确定 3
2.1  主机结构方案拟定 3
2.2  基本参数确定计算 3
2.2.1  工作重量m 3
2.2.2  前后轮分配重 3
2.2.3  重心位置的确定 3
2.2.4  压轮直径 4
2.2.5  压轮宽度 4
2.2.6  前后轮静线载荷 4
第三章:振动压实机理 7
3.1土的抗剪强度及特点 7
3.2振动对土的剪切应力和抗剪强度的影响 7
第四章:振动压路机结构 9
4.1振动压实理论的几种学说 9
4.2振动压路机的形式 9
4.3振动压路机的振动轮结构 10
4.4二自由度振动压路机一土壤系统动力学模型 10
4.5振动压路机参数选择简介 11
第五章  油箱的设计 29
5.1  油箱容量的确定 29
5.2  油箱尺寸的确定 29
5.3  油箱的散热验算 29
5.3.1  系统发热量计算 29
5.3.2  液压系统的散热功率计算 30
5.4  油箱附件的选择与结构设计 31
5.5  油液的选择 32
致谢
部分图纸截图
