设计名称
喷涂机送料机构结构设计【说明书+CAD】
设计编号
JX1967
设计软件
AutoCAD,Word
包含内容
见右侧图片
说明字数
见下方截图
图纸数量
见右侧图片
推荐指数
较高
价格
价格优惠中
整理日期
2019-05-03
整理人
admin
设计简介
中文题目:油漆喷涂机送料机构结构设计
摘要
喷涂机是一种将涂料分散成雾状喷涂于被涂物表面的专用涂装设备,其工作机构主要包括有喷头的喷涂室、传送带、干燥系统、清洁机构和回收系统等。由于喷涂机具有喷涂效率高、喷涂均匀、油漆利用率高、易于操作等优点,所以被广泛应用于工业生产中。
本次毕业设计的课题是油漆喷涂机送料机构结构设计,其中设计内容主要包括:1、送料机构的整体外形和尺寸设计。2、设计夹紧机构的结构,并对比各种方案,选择最优方案。3、输送带的设计。4、夹紧机构的强度设计。5、设计送料机构的工作台。
本次毕业设计旨在设计出一个能够对工件进行自动送料的送料机构。压紧机构作为送料机构的主要部件,它不仅要能控制工件的左右位置,还要能控制工件的上下位置,因此,压紧机构的结构设计是最重要的部分。在设计过程中,要根据压紧机构的原理设计出几种压紧机构的机构简图,并对不同的方案进行对比。在本文中选出了三种不同的方案进行对比选择,最后选择出最优的方案,再对其进行尺寸设计。除了夹紧机构的设计外,工作台的设计也是其中的一个重点。由于工件的大小可能不一,所以要求夹紧机构能够上下左右移动。
本文除了设计过程的阐述外,还对喷涂机进行了简单的介绍,并且就喷涂机的国内外发展情况进行了介绍和分析。
关键词:喷涂机、压紧机构、输送带、工作台

 Subject:Structural design of the spray chamber of the sprayer

Abstract
The sprayer is a paint dispersed into a mist sprayed on the surface to be painted a special painting equipment, its agencies including the nozzle of the spray booths, conveyors, drying system, clean bodies, and recycling systems, etc. Spraying machine has the advantages of high efficiency spray, spray evenly, paint utilization, ease of operation, it is widely used in industrial production.
The subject of this graduation project is a paint spraying machine feed mechanism structural design, including design and content including: 1, the feed mechanism as a whole shape and size of the design. 2, the design structure of the clamping mechanism, and compare the various options and choose the best program. 3, the design of the conveyor belt. 4, the strength design of the clamping mechanism. Design table feed mechanism.
The graduation project is to design an automatic feed of the workpiece feed mechanism. Pressed institutions as the main components of the feeding mechanism, it must not only be able to control the left and right position of the workpiece, but also be able to control the upper and lower positions of the workpiece, therefore, the structural design of the compression bodies is the most important part. According to the principle of compression bodies in the design process, design the institutions of several compression diagram, and compare the different options. Elected three different scenarios in this paper were compared to select the final choice of the optimal solution, its size design. In addition to the clamping mechanism design, bench design is a key. As the size of the workpiece may vary, so the clamping mechanism can up and down and move around.
In addition to the design process elaboration on the sprayer a brief introduction, and spraying machine at home and abroad, the development of presentations and analysis.
Key wordsspraying machine, pressed institutions, conveyor belt, bench,
部分图纸截图
