Abstract
Belt conveyors are the main transportation equipment for bulk materials such as coal port terminals. Through friction, power is transmitted. The friction force of the drive roller comes from the tension between the conveyor belt and the roller. The tension is achieved through the tensioning system. Through the design of the tensioning system, the design process of a typical general machinery can be mastered. The tension of the belt conveyor is achieved by tensioning the winch. This design is based on the analysis of the working principle, working environment and work characteristics of the tension winch, combined with the actual, after careful observation, the overall structure of the tension winch is designed, and the components are selected. Type, calculation and check. In order to develop more advanced tension winches, it has important research significance for the development prospects of tension winches. In today's era, tension winches are important equipment for mechanical processing in the machinery industry, so their research capabilities and development status have also contributed to the development of the entire industry of tension winches. At present, the inherent potential value of the tension winch industry in China remains to be tapped vigorously. Further research on the tension winch will bring important positive significance to the company and the entire machinery industry and society. While studying, it can also enable students to The overall ability is developed and exercised. The most important thing is that the overall design reflects this. First, we must let the now-graduated students lay the foundation for professional knowledge and thus enhance the knowledge they have learned so that they can do their job in the future. Second, they can allow them to look at issues with a development perspective in their projects, give full play to their innovative capabilities, and break through real-world problems. For the topic of tension winch design, its culvert has a wide range of knowledge and is extremely comprehensive. Students must rely on their excellent professional skills and vast knowledge, plus they must have a certain degree of computer graphics. ability. Therefore, students can actively think and delve into this design topic, so that students can gain the ability to analyze and solve problems, and thus can also accumulate work experience that will help the future.
This paper mainly describes the development history of hydraulic technology of tension winch and its current development situation at home and abroad, and briefly describes the development trend of hydraulic tension winches. At the same time, this paper briefly describes and analyzes the common hydraulic circuit of the hydraulic tension winch, designs and analyzes the small hydraulic tensioning system designed for the subject, and determines the required hydraulic components to complete the selection through further calculations. Use AutoCAD to draw schematics for the hydraulic system, work tank assembly, hydraulic layout, and tank parts drawings. Finally, the feasibility of this design was verified by checking.

Keywords   conveyor  hydraulic system  tensioning winch  design

目       录
摘 要 Ⅰ
Abstract Ⅱ
1绪 论 1
2张紧绞车设计方案 4
2.1张紧绞车设计要求 5
2.2确定液压系统方案 5
2.3张紧绞车总体结构 6
3张紧绞车各部分设计 7
3.1钢丝绳的选择 7
3.1.1钢丝绳直径计算 8
3.1.2钢丝绳强度校核 9
3.2卷筒设计 9
3.3卷筒轴的设计 11
3.4减速器的选择 16
3.4.1减速器方案的比较 16
3.4.2减速器型号及相关参数的确定 17
3.4.3减速器强度的校核 18
3.4.4减速器输出轴轴端负荷的校核 19
3.5 机架设计 19
4 张紧绞车液压系统设计 20
4.1基本方案的制定 20
4.2液压系统的绘制 21
4.3 液压元件计算与选择 22
4.3.1 液压马达 22
4.3.2 液压泵 23
4.3.3液压阀 24
5 液压站的设计 26
5.1 液压站的组成及类型 26
5.1.1 液压站的组成 26
5.1.2油箱的用途 26
5.1.3 油箱的计算 27
5.2选择过滤器 30
5.3 油管和管接头的选择 32
5.3.1油管的选择 32
5.3.2管接头的选择 32
结论 33
致谢 34
参考文献 35
