This design is the design of the screw conveyor. Here mainly includes: the design of transmission system of the screw conveyor. The graduation design on the design of the basic skil training, improve the analysis and the ability to solve engineering problems, and create a certain condition for general mechanical design.
The structure is mainly generated by the motor power through the coupling will need to transfer the power to the screw, screw through the spiral movement of material moving a certain position, screw conveyor, but ao show its superiority, there are broad prospects for the development.
The content of this paper:
(1) the overall structure design of the screw conveyor.
(2) the working performance analysis of screw conveyor.
(3) the choice of motor.
(4) the design of transmission system, executive component of screw conveyor.
(5) the design of parts of the design calculation and check.
(6) parametric design
(7) the assembly drawing and parts drawing assembly drawings and parts drawings design.
Key Words: screw conveyor; continuous conveyors; parametric design
