口腔咀嚼模拟机器人机械设计及仿真

摘  要

机械手是一种典型的机电一体化产品，口腔咀嚼模拟机器人是机械手研究领域的热点。研究口腔咀嚼模拟机器人需要结合机械、电子、信息论、人工智能、生物学以及计算机等诸多学科知识，同时其自身的发展也促进了这些学科的发展。
本文对一种使用在口腔咀嚼模拟机器人的结构进行设计，并完成总装配图和零件图的绘制。要求对机械手模型进行力学分析，估算各关节所需转矩和功率，完成电机和减速器的选型。其次从电机和减速器的连接和固定出发，设计关节结构，并对机构中的重要连接件进行强度校核。
关键词　结构设计，机器臂，结构分析
Mechanical design and Simulation of the oral chew simulation robot

Abstract

The manipulator is a kind of typical mechatronic product, and the robot is the hot spot in the research field of robot manipulator.. Study on chewing simulated robots need combination of machinery, electronics, information theory, artificial intelligence, biology and computer knowledge of many disciplines, also its development also contributed to the development of these disciplines.
In this paper, the structure of a robot used in oral chewing is designed, and the assembly drawings and the drawing of the parts are finished.. The mechanical hand model is demanded to analyze the mechanical hand, and estimate the torque and power of each joint, and complete the selection of motor and reducer.. Secondly, from the connection and the fixed of the motor and the reducer, design the joint structure, and carry on the strength check to the important connector in the mechanism.
Keywords　 structure design, robot arm, structure analysis
目  录
