摘 要

本次设计是螺母提升机设计的设计。在这里主要包括:机架系统的设计、链传动系统的设计、调整机构系统的设计、的设计。这次毕业设计对设计工作的基本技能的训练，提高了分析和解决工程技术问题的能力，并为进行一般机械的设计创造了一定条件。
整机结构主要由电动机产生动力通过联轴器将需要的动力传递驱动装置上，小链轮带大链轮，从而带动整机运动，螺母提升机更显示其优越性，有着广阔的发展前途。
本论文研究内容：
(1) 螺母提升机总体结构设计。
(2) 螺母提升机工作性能分析。
(3)电动机的选择。
(4) 螺母提升机的传动系统、执行部件设计。
(5)对设计零件进行设计计算分析和校核。
(6)绘制整机装配图及重要部件装配图和设计零件的零件图。
关键词：螺母提升机， 联轴器，滚珠丝杠

Abstract

This design is the design of machine design of the lifting nut. Here mainly include: rack system design, chain drive system design, system design, adjustment mechanism design. The graduation design on the design of the basic skills training, improve the analysis and the ability to solve engineering problems, and created certain conditions for general mechanical design.
The structure is mainly composed of the motor power will need to transfer the power of the driving device through the coupling, chain wheel sprocket, so as to drive the movement, the nut lifting machine but also show its superiority, there are broad prospects for the development.
The content of this paper:
(1) the overall structure design of the lifting nut machine.
(2) performance analysis machine lifting nut.
(3) the choice of motor.
(4) enhance the nut transmission system, machine component design.
(5) the design of parts design calculation and check.
(6) drawing machine assembly and important parts assembly drawings and parts drawings design.
Keywords: nut hoist, coupling, ball screw
