摘要：本次毕业设计是关于垂直升降类立体停车库提升装置的设计，首先对立体停车库作了简单的概述；接着分析了该提升装置的方案布局及工作原理，然后根据这些设计准则按照给定参数要求进行选型设计；接着对所选择的提升装置各主要零部件进行了校核。垂直升降类立体停车库提升装置由驱动机构，机架，搬运器，以及钢丝绳轮传动等几个部分组成。目前，垂直升降类立体停车库正朝着长距离，高速度，低摩擦的方向发展，近年来出现的气垫式提升装置就是其中的一个。在垂直升降类立体停车库的设计、制造以及应用方面,目前我国与国外先进水平相比仍有较大差距,国内在设计制造垂直升降类立体停车库过程中存在着很多不足。
      本次设计是关于垂直升降类立体停车库提升装置设计，通过对传统的垂直升降类立体停车库提升装置的结构进行了改进和优化，使得此种类型的提升装置的使用范围更广泛，更加灵活，并且对今后的选型设计工作有一定的参考价值。
关键词：垂直升降类立体停车库提升装置；驱动机构；制造；参考价值
   Abstract：This graduation design is the optimization design of driving roller conveyor, first on the driving roller type conveyer is summarized; then analyzed the selection principle and calculating method of driving roller conveyor; then calculated based on these design criteria and abase is designed; then checked on the main parts selected conveyor. Is the drive roller conveyor consists of four main parts: driving device, tension device, middle rack, and the moving part. Finally, a simple description of the installation and maintenance of transport. At present, the drive roller conveyor is moving towards long distance, high speed, low friction direction, air cushion conveyor in recent years is one of the. In the design, driving roller type conveyer manufacture and application, at present our country compared with foreign advanced level there are still large gaps, domestic in the design and manufacture of driving .
