摘  要
本文论述了转弯机输送带导向条装配夹具的设计过程。设计在保证安全的前提下，力求简洁紧凑。该设计主要由导向条定位夹具和导向条折弯夹具装置：定位夹具即为导向条平直段时的定位夹具，折弯夹具靠自动折弯成型。该转弯机输送带导向条装配夹具使用可以实现导向条自动折弯，并且人工可以单班多次工作，具有机构简单，效率高，使用方便的特点。

关键词:定位夹具；自动折弯夹具；自动折弯成型
ABSTRAC

This article discusses the turning conveyor belt guide bar assembly fixture design process. Designed under the premise that security is guaranteed, concise compact. The design is driven mainly by the positioning fixture and the guide bar bending fixtures Article: Article positioning fixture is the orientation of the positioning fixture straight segment, bending fixture by automatic bending shape. The turning conveyor belt guide bar assembly fixture can be achieved using the automatic bending-oriented, and multiple single-class working man can have organization is simple, efficient, easy to use features.
Key Words：Positioning fixture; automatic bending fixture; automatic bending forming
