设计简介
摘要
本文设计了了一种新型的娱乐工具——水陆两用自行车。水陆两用自行车在动力方面与传统自行车一样，都是靠人力驱动，通过链传动将动力传递给后轴。后轴上连接两个可单独控制，互不影响的明轮，实现水陆两用自行车在水上的行进与转向。同时为了保证在水上行驶的安全性，将浮板设计成三角形与水陆两用自行车固定，使得行驶安全、轻松、自在。
关键词：水陆两用自行车、链传动、明轮、浮板。
Abstract
This paper presents a new kind of entertainment tools——Amphibious bicycle. Amphibious bicycle in power are the same as with the traditional bicycle driven by human, and through the chain drive transfers power to the rear axle. Rear axle are connecting two paddle wheel that can be controlled separately and are independently of each other in order to traveling and steering in the water. The float board are designed into a triangle which are fixed witch the amphibious bicycle in order to ensure the safety of driving in the water, you can feel the traveling safe, relaxed and comfortable.
Key words: Amphibious bicycle 、Chain transmission、 Paddle wheel、 Kickboard.
目录
摘要…………………………………………………………………………3
Abstract……………………………………………………………………4
第一章绪论…………………………………………………………………5
1.1研究背景………………………………………………………………5
1.2发展前景………………………………………………………………6
第二章总体方案设计……………………………………………………8
2.1水陆两用自行车的构成……………………………………………8
2.2水陆两用自行车方案设计…………………………………………10
第三章浮力…………………………………………………………………10
3.1浮力计算………………………………………………………………10
3.2浮板的设计……………………………………………………………11
3.3浮板材料选用…………………………………………………………12
第四章动力计算……………………………………………………………12
4.1功率的计算……………………………………………………………12
4.2传动比…………………………………………………………………13
4.3链传动设计……………………………………………………………13
第五章轴的设计……………………………………………………………16
5.1链轮上力的计算………………………………………………………16
5.2选取材料………………………………………………………………16
5.3计算轴的最小直径……………………………………………………17
5.4轴的结构设计…………………………………………………………17
第六章明轮的设计…………………………………………………………18
6.1明轮简介…………………………………………………………………18
6.2明轮的设计………………………………………………………………19
第七章 三维作品展示………………………………………………………20
第八章结论……………………………………………………………………31
第九章 本次设计外购件清单…………………………………………32
参考文献………………………………………………………………………34
致谢………………………………………………………………………………35
