钢卷自动上料小车研究

摘  要

钢卷，也被称为卷钢，钢材经过热、冷压成型为卷状。为了方便储存和运输，各种钢材的暂时处理方法（如加工成钢带等。）。
钢卷包装是钢卷储存和运输的重要保护措施。传统的钢卷包装为手工作业,包装质量差、生产效率低和工人劳动强度大是这一落后包装技术的致命弱点。特别是,随着轧制速度的提高,新建的冷轧生产线的能力都在百万吨级,低效率的手工包装根本不能满足生产要求。工业发达国家的钢铁企业都非常重视钢卷包装,将其提高到 保证安全储运,提升产品档次!的高度,开发出完整的钢卷包装工艺技术和装备,基本实现了钢卷包装的自动化。
本文对钢卷自动上料系统进行设计，主要完成机械结构部分设计，最后还对小车的控制系统进行了PLC控制设计。
关键词    钢卷；机械结构；自动上料
Steel Coil Automatic Feeding Vehicle research

Abstract

Steel coil, also known as the steel coil, steel after heat, cold pressing roll. In order to facilitate storage and transportation, temporary processing methods of different kinds of steel (such as processed into steel belt and so on.).
Steel coil packaging is an important protection measures of steel storage and transportation. The traditional steel coil packaging for manual operation, the packaging of poor quality, low production efficiency and high labor intensity of workers is the backward packaging technology of the fatal weakness. Especially, with the rolling speed, capacity of the new production line of the cold rolling mill in million tons, the low efficiency of manual packaging does not meet the requirements of production. Industrial developed countries have attached great importance to the iron and steel enterprises steel coil packaging, it will be increased to ensure the safety of storage and transportation, enhance the grade of products! Height, developed a complete steel rolling technology and equipment package, the basic realization of the automated packing steel roll.
The steel coil automatic feeding system design, mainly completes the design of mechanical structure, the control of the car system is the design of PLC control.
Key Words: Steel rolling; mechanical structure; automatic feeding
