摘  要

行星齿轮减速器是一种至少有一个齿轮的几何轴线绕着固定位置转动圆周运动的传动，变速器通常和若干行星轮和传递载荷的作用，为了使功率分流。渐开线行星齿轮传动具有以下优点：传动比大，结构紧凑，体积小、质量小，效率高，噪音低，运转平稳，因此被广泛应用于冶金，工程机械，起重，运输，航空，机床，电气机械及国防工业等部门，作为减速、变速或增速的齿轮传动装置
NGW型行星齿轮传动机构的传动原理：当高速轴由电机驱动，带动太阳轮，然后带动行星轮转动，内齿圈固定，然后带动行星架输出运动的，在行星架上的行星轮既自转和公转，具有相同的结构。二级，三级或多级传输。NGW型行星齿轮传动机构主要由太阳齿轮，行星齿轮，内齿圈，行星架，命名为基本成分后，也被称为zk-h型行星齿轮传动机构。
本设计是基于行星齿轮结构设计的特点，和SolidWorks三维建模和运动仿真。行星齿轮和各种类型的特性的比较，确定方案；其次根据输入功率，相应的输出转速，传动比的传动设计、总体结构设计；三维建模并最终完成了SolidWorks，和模型的装配，并完成了传动部分的运动仿真和运动分析。
关键词： 行星齿轮减速器、运动仿真、装配、三维建模

Planetary gear reducer is driving a at least one gear geometric axis rotated around a circular motion of fixed position, the transmission is usually and planetary gear and transfer load, in order to make the power split. Involute planetary gear transmission has the following advantages: large transmission ratio, compact structure, small volume, small mass, high efficiency, low noise, smooth operation, so it is widely used in metallurgy, engineering machinery, lifting, transportation, aviation, machine tools, electrical machinery and defense industry and other departments, as gear reducer, gear or the growth
The transmission principle of NGW type planetary gear transmission mechanism: when the high-speed shaft driven by a motor, to drive the sun gear, and the planet wheel is driven to rotate, the inner gear ring is fixed, and then drives the planetary frame outputting motion, on the planet carrier planet wheel both rotation and revolution, has the same structure. The two level, three level or multilevel transmission. The NGW type planetary gear transmission mechanism mainly consists of a sun gear, planet gear, inner gear ring, a planetary frame, named after the basic components, also known as the ZK-H type planetary gear transmission mechanism.
This design is the design of planetary gear structure based on SolidWorks, and 3D modeling and motion simulation. Comparison of characteristics of planetary gears, and various types of determination scheme; secondly according to the input power, the output speed of the overall design, transmission design, ratio; 3D modeling and finished SolidWorks, assembly and model, and the motion simulation and motion analysis of the transmission part.
Keywords: planetary gear reducer, assembly, motion simulation, 3D modeling
