设计简介
摘要
压滤机是利用多孔性过滤介质,拦截混合固体颗粒的液体和固体颗粒,实现固体和液体分离的设备。压滤机广泛应用于化工、石油、制药、轻工、食品、选矿、煤炭和水处理等。目前,现有数百个大型压滤机制造商。为了满足产业发展的需求,市场上已经出现了各种不同的类型压滤机。根据获得过滤的推动力不同,分为重力过滤,真空过滤机和三种类型的压滤机。板框压滤机压紧方式有手动压缩、机械压缩和液压三种形式。正在开发一种新型的过滤设备有:机械力压过滤设备;实现无动态过滤滤饼层;洗煤废水处理、化工和石油等行业大型过滤设备。设计的手工板框过滤机。它的优点是结构简单,容易制造,过滤面积大,占地面积小,操作压力高、能力强的各种材料的应用,主要用于小企业,小批量生产。
关键词：过滤机 过滤面积 滤板 滤框
Abstract
Filter is the use of porous filter medium, retain the mixture of liquid and solid particles, solid particles, and to achieve solid, liquid separation equipment. Filter is widely used in chemical, petroleum, pharmaceutical, light industry, food, mineral processing, coal and water treatment sectors. Currently, hundreds of our existing large filter manufacturers. To meet the requirements of the industry and the market has been the emergence of various different models and methods of filter .Be driven by different methods of filtration, divided into gravity filters, vacuum filters and pressure filter categories. Pressed mode frame filter press with manual compression, mechanical compression and hydraulic clamping three forms. Is developing a new type of filtration equipment: mechanical press filtration equipment; to achieve residue-free layer of filtering a dynamic filter; Coal washing waste water treatment, chemical and oil industry equipment used in large filtration. The design of the filter frame for the hand over machine. It has the advantage of simple structure, easy to filter area and small size, operating pressure is high, the application of the ability of various materials, mainly small-batch production and small business applications
Key Words：Filter Filter area Plates Filter box
目录
摘要 I
Abstract II
绪论 1
1 板框压滤机 2
1.1 板框压滤机的起源 2
1.2 板框压滤机的简介及分类 2
1.3 板框压滤机的结构 2
1.4 板框压滤机的工作原理 2
2. 板框压滤机的设计 3
2.1 板框压滤机的过滤原理及特点 3
2.1.1 板框压滤机的结构 3
2.1.2 板框压滤机的流程 4
2.1.3 滤布的选型 5
2.2 过滤机的参数 5
2.3 滤板和滤框的设计以及强度计算 6
2.3.1 板框和滤板材料选择 6
2.3.2 滤板的强度计算 7
2.3.3 滤框的强度计算 8
2.4 螺杆的设计及计算 9
2.4.1 螺杆螺纹类型的选择 10
2.4.2 选取螺杆材料 10
2.4.3 确定螺杆直径 10
2.4.4 自锁验算 10
2.4.5 稳定性计算 10
2.4.6 校核螺纹牙强度 11
2.5 横梁设计 12
2.6 压紧板设计 12
2.6.1 轴承的选择 13
2.7 支座组件 14
2.7.1 螺栓的校核 15
2.8 操纵阀组件设计 15
2.8.1 螺杆套筒剪切力校核 16
2.8.2 手轮与螺杆联接 16
2.9 安装及调试 16
3. 板框压滤机的操作规程 18
4. 板框压滤机的保养维护 19
结 束 语 20
参 考 文 献 21
致 谢 22
