设计简介
摘 要
机械工业的生产水平是一个国家现代化建设水平的主要标志之一。而总体看来我国的生产力水平较低，技术不发达。随着机械产品国际市场竞争的日益加剧,各大公司都把高新技术注入机械产品的开发中,作为竞争取胜的重要手段。
该篇论文是对CK6136H车床尾架的结构分析与工艺设计。本论文主要包括车床尾架零件的平面二维图绘制及三维实体设计；车床尾架的结构分析；尾架体及套筒工艺分析；对套筒制定零件的加工工艺过程，拟定工艺卡。通过查找资料和实际中对尾架的使用以及尺寸的测量、咨询老师等方法，熟悉车床尾架的内部结构，结合实际改进车床尾架结构，以提高车床加工精度。
通过此次设计，真正熟悉车床尾架的内部结构与加工工艺，把所学的知识运用到生产实践中去。
关键字：CK6136H；车床尾架；结构分析；工艺设计
ABSTRACT
Mechanical industrial production level is the level of a country's modernization, the mainlandmark. Overall productivity of the low level of technology developed. With themechanical products in the international market, increasing competition, companies regarded the development of high-tech products into the machine, as a competition to win an important segment..
This paper is about the CK6136H lathe tail stand structure analysis and the technological design. This design instruction booklet mainly includes the lathe tail stand components the plane two dimensional plot plan and the three dimensional entity design; Lathe tail stand structure technology capability analysis; Carries on the technological design, the formulation components processing craft, draws up the operation code. And actual consults methods and so on teacher through the search material to the tail stand use as well as the size survey, the familiar lathe tail stand's internal structure, the union actual improvement lathe tail stand structure, increases the lathe working accuracy. through this design, the genuine familiar lathe tail stand's internal structure and the processing craft, the knowledge which studies utilizes in the production practice..
Key words：CK6136H；Lathe tail stand；Structure analysis；Technological design
