摘要

摘要：为了解决高速线材生产线收集区输送设备P/F线横向浮动式直线驱动装置的种种设计缺陷和不足，更好的满足生产工艺的要求，对驱动装置重新进行设计，采用履带式直线驱动装置。过载安全保护由原来的安全销改为履带过载打滑保护并且增加了浮动过载保护装置增强了设备的安全性，加大外形尺寸的传动轴通过固定轴承钨以后再与减速机相连接，保证了驱动装置提供足够的驱动力，可调整的张紧链轮及链条支撑机构使得安装调整链条啮合间隙更加方便，新设计的快速切换装置使得驱动之间的切换更加迅速，以上的种种设计从根本上弥补了横向浮动式直线驱动装置的设计缺陷，保证了P/F线更加安全稳定的运行。
关键词：横向浮动式    设计     履带式   直线驱动装置
 Abstract

Abstract: In order to address the collection of high-speed wire production line conveyor equipment area P / F Floating horizontal line drive straight all the defects and deficiencies in the design, production processes and better meet the requirements of re-drive design, the use of track-type linear drive unit . Overload protection of the safety pin changed from the original track skid overload protection and overload protection device to increase the floating equipment to enhance security, increase the size of the drive shaft through a fixed bearing tungsten later connected with the reducer to ensure that the driver device to provide sufficient driving force, adjustable chain tensioning sprocket support and allow institutions to adjust the chain meshing clearance more convenient, the new fast-switching devices designed to make drivers more quickly switch between, the design of the above make up a fundamental Floating horizontal straight-line defects in the design of drive to ensure that the P / F line to run a more secure and stable.
Key words: horizontal floating   design
 Crawler    drive a straight line
