桨叶式搅拌机的设计
摘要：为了提高加工效率，本课题设计了一种出料粒度为15～20mm的桨叶式搅拌机，根据要求设计了锤击部分和反击部分。 物料由进料口进入破碎腔，经过锤头的冲击、剪切、劈碎、折断，实现物料的中碎；锤击的物料冲击到安装在破碎腔内的反击板上，又经过物料与反击板、物料与物料的互相冲击,从而实现了物料的细碎。本机融合了锤式搅拌机、反击式搅拌机与桨叶式搅拌机的优点,降低了生料和熟料的入磨粒度，较好地达到了设计要求。
关键词：搅拌机；反击板；锤头

The designe of Vertical spindle type breaker

Abstract: In order to enhance the processing efficiency, this topic has designed one kind of material granularity is 15 ~ 20mm vertical spindle type breaker, according to requested to design has hammered the part and the counter-attack part. The material by enters the broken cavity, after the hammer head impact, cuts, chops into pieces, breaks off, the realization material center is garrulous; Hammers the material attacks installs in the broken cavity on the counter-attack board, also passes through the material and the counter-attack board, the material and the material mutual impact, thus has realized the material fragmentation. This machine fused the hammer type breaker, the counter-attack type breaker and the vertical spindle type breaker merit, reduced the crude material and the chamotte enters rubs the granularity, has met the design requirements well.
Keywords: breaker; counter-attack board; hammer head
目录
1前言………………………………………1
2概述……………………………………..2
3 总体方案论证………………………….5
4 传动装置的总体设计…………………….6
5 桨叶式搅拌机主要参数的确定………9
6 相关零件的设计……………………..22
7 辅助零件的设计……………………….23
8 结论 ………………………………….25
参考文献………………………………….26
致    谢………………………………….27
