0.8 m3/min涡旋式空气压缩机设计简介
摘 要
涡旋式压缩机是一种高效、节能、省才和低噪声的新型容积式压缩机，可广泛的应用在空调、制冷、真空和各类气体压缩等方面，且可望取代传统的其他类型的小型压缩机。涡旋压缩机主要有动涡旋、静涡旋、防自转机构等部件构成，压缩机设计的关键问题有以下几个方面：一是涡旋齿的型线选择及其修正；二是基本参数的选取；三是防自传机构的设计；四是动平衡的设计；五是轴承的选择；六是曲轴及涡旋齿面强度的校核；七是机体运动部件的润滑及其整机密封的设计。本压缩机采用圆渐开线型线，防自传机构采用十字环，驱动方式采用直连式，整机采用压差供油润滑。
关键词： 涡旋式压缩机 型线 防自传机构 动平衡
Abstract
Summary of scroll compressor is an efficient, energy saving, low noise Province before and the new positive displacement compressor can be widely used in air conditioning, refrigeration, vacuum and various gas compression, etc., and the other is expected to replace the traditional types of small compressors. scroll compressor is mainly composed of a fixed scroll 、an orbiting scroll and antirotation .Compressor design has the following key issues: First, wrap the type of line selection and correction; the second is the selection of basic parameters; Third, the design of anti-autobiography institutions; Fourth, the design of dynamic balance; Fifth bearings choice; Sixth, the crankshaft and check the strength of tooth surface vortex; seventh, lubricating moving parts of the body and the whole seal design. The compressor Involute circle, anti-autobiography organizations to adopt cross ring, using direct-attached drive, the machine uses pressure lubrication. Keywords: scroll compressor body type line balancing anti-autobiography.
