设计名称
直齿罗拉滚齿形加工工艺及工装夹具设计【说明书+CAD】
设计编号
JX1572
设计软件
AutoCAD,Word
包含内容
见右侧图片
说明字数
见下方截图
图纸数量
见右侧图片
推荐指数
较高
价格
价格优惠中
整理日期
2019-12-29
整理人
admin
设计简介
摘要
为满足零件加工工艺要求,解决零件上尺寸精度、圆弧形状精度、相互位置精度。根据零件的用途、作用及外形、工艺要求,对该零件的加工工艺进行了详细的分析。机械加工工艺规程一般包括以下内容:工件加工的工艺路线、各工序的具体内容及所用的设备和工艺装备、工件的检验项目及检验方法、切削用量、时间定额等。
对罗拉齿形的加工,可以采用铣加工和刨加工,分析两种加工方式,选择了更加合适的刨加工,在加工时由于罗拉零件的特殊性,需要设计出一种专用于罗拉齿形加工的夹具体。在设计夹具时,要注意到工装夹具应具备足够的强度和刚度,夹具的可靠性和灵活性以及良好的工艺性。
关键词
罗拉     加工工艺     工艺分析      工装设计

Abstract

To meet the technological requirements of machining parts, solve the dimension precision, arc shape accuracy, mutual position precision. According to parts of the applications, function and appearance, technical requirements, the machining process of the part to carry on the detailed analysis. The machining process procedures generally includes the following content: workpiece machining processing route, the process of concrete content and used equipment and process equipment, workpiece inspection items and inspection method, cutting dosages, time quota etc.
For Laura tooth-type processing, can use milling and planing processing, analysis of two processing methods, chose a more suitable shaver processing, in processing the particularity of because Laura parts need to design a kind of dedicated to Laura tooth-type processing the clip concrete. In design fixtures, want to notice the fixture should have enough strength and rigidity, fixture reliability and flexibility and good workmanship.
keywords
Laura         processing technology       process analysis        tooling design
目录
1.罗拉的零件外形,结构特点,及加工工艺 1
2.罗拉零件的加工工艺 3
2.1下面对轴头进行加工过程的工艺分析: 4
2.1.1轴类零件的毛坯 4
2.1.2确定主要表面的加工方法 4
2.1.3确定定位基准 5
2.1.4热处理工序安排 5
2.1.5下面是对罗拉齿形加工的工艺分析 11
2.2夹具的设计 13
2.2.1夹具主支撑的设计过程 15
2.2.2辅助支撑的设计 19
2.2.3分度装置的设计 21
2.2.4压紧装置的设计 23
3.数控加工程序 26
4.夹具的经济性分析 27
5.总结 28
6.参考文献 29
