设计名称
电饭煲传感器外壳冲压工艺与模具设计【说明书+CAD】
设计编号
JX1087
设计软件
AutoCAD,Word
包含内容
见右侧图片
说明字数
见下方截图
图纸数量
见右侧图片
推荐指数
较高
价格
价格优惠中
整理日期
2018-06-22
整理人
admin
设计简介
摘要:学习、研究和发展冷冲压技术,对发展我国国民经济和加速现代化工业建设具有重要意义。本文主要是对电饭煲传感器外壳的工艺分析及模具设计。首先,对电饭煲传感器的外壳进行了工艺分析,电饭煲传感器外壳的外形是圆柱形,确定了毛坯尺寸、拉深次数、模具的结构形式及排样方式;然后选择了合适的压力机,把凹模、凸模的尺寸设计出来、选择了合适的模架、卸料装置、推件装置、导向零件、模柄、凸模和凹模的固定板及垫板;最后用dynaform对设计的模具进行了纺真验证,用CAD软件绘制了本模具的工程图。

关键词:冷冲压  圆柱形  工艺分析
Abstract:The study, research and development are cold to hurtle to press a technique, to development our country national economy and acceleration modernize industrial construction to have important meaning.This text is mainly craft analysis and molding tool design which spreads a feeling machine outer shell to the rice cooker.Spread the outer shell of feeling machine to carry on a craft analysis to the rice cooker first, made sure semi-finished product size and pull structure form and the row kind method of deep number of times, molding tool;Then chose suitable pressure machine, come out, chose the size design of cave and convex mold a suitable mold, unload to anticipate device and push a device, the direction spare parts, mold handle, convex mold with fixed plank and plastic sheet of cave mold;Finally drew the engineering diagram of this molding tool with the CAD software.

Keywords: cold to hurtle  Cylinder form  Craft analysis
目录

1 引言 1
1.1背景 1
1.2冷冲模成形特点 1
1.2.1冲裁模 2
1.2.2弯曲模 2
1.2.3拉深模 2
1.2.4多工位级进模 3
1.3冷冲模具的发展趋势 3
1.3.1有限元分析商业软件简介 4
1.3.2 DYNAFORM软件简介 5
1.4复合模 6
1.4.1 概述 6
1.4.2 复合模的种类 7
1.4.3选择复合模的原则 8
1.4.4 复合模的设计要点 8
1.5冲压加工的经济性 10
1.5.1冲压件的制造成本 10
1.5.2降低成本的措施 10
2 冲压件工艺性分析 11
2.1制件的工艺分析 11
2.2拉深次数 11
3模具设计 13
3.1毛坯尺寸的确定 13
3.2工艺方案的选择 13
3.2.1模具的结构形式 13
3.2.2冲裁力 14
3.2.3卸料力、推件力和顶件力 14
3.3排样 15
3.4 压边力与拉深力 16
3.4.1 压边力 16
3.4.2 拉深力 16
3.5 模具压力中心和闭合高度的确定 16
3.6 压力机的选择 16
3.7 模具主要零部件的设计 17
3.7.1 落料凹模的结构设计 17
3.7.2 冲孔凸模的结构设计 19
3.7.3凸凹模的结构设计 20
3.8模具标准件的选择 21
3.8.1 模架的选择 21
3.8.2挡料销 22
3.8.3卸料装置 23
3.8.4推件装置 24
3.8.5导向零件设计与标准 24
3.8.6模柄的选用 25
3.8.7凸模固定板与垫板 25
3.8.8压缩橡皮的选用 25
3.9拉深模结构设计 27
3.9.1凸、凹模间隙 27
3.9.2凸、凹模制造公差 27
4 DYNAFORM仿真验证 29
结论 32
参考文献 33
鸣谢 34

部分图纸截图
