设计简介
摘 要
模具是工业生产的基础工艺装配，广泛应用于机械、汽车、电子通讯、家电等行业，其中有80%以上的产品零件均通过模具生产而成。在国际上，模具又有“工业之母”之称。模具分为冷冲压模具、热锻模具、塑料模具、铸造模具、橡校模具和玻璃模具等。其中冷冲压模具在各种模具中所占比重最多，占整个模具市场的60%以上，具有广泛的发展前景。
冷冲压模具是在室温下，借助于设备提供的压力，利用模具使板料发生分离成塑性变形的一种加工方法。加工对象主要是金属或非金属的板料。
本设计是对给定的模具产品图进行冲压工艺分析和连续模设计，在综合考虑了加工产品的经济性、零件的冲压工艺性以及复杂程度和精确度等诸多因素的基础上进行冲压工艺分析与计算的，并提出了合理的工艺方案和结构形式；最后，结合产品的工艺及现有加工方法合理设计连续模排样方案及加工方法最终达到省时省料、节约资源的目的。本设计介绍了模具设计中的排样与送料方式和卸料与导向方式，讨论了主要工作件间隙的确定和刃口尺寸及冲压力的计算，并选择合适的压力机，设计中主要对模具工作部分尺寸进行计算和主要零部件的设计以及加工工艺的制定。
总而言之冲压模的加工生产效率高，加工成本低，材料利用率高，产品的一致性好，制件质量符合生产要求,且操作简单。
关键词：前板 冲压 工艺分析 连续模
Abstract
Mold is the basis of industrial production assembly process is widely used in machinery, automobile, telecommunications, home appliances and other industries, including more than 80% of the product parts are made through the mold production. At the international level, mold and "Mother of industry" called. Is divided into cold stamping die mold, forging mold, plastic mold, die casting, rubber mold school, such as mold and glass. One cold stamping die mold in a variety of the largest share, accounting for the entire mold more than 60% of the market, has a broad development prospects.
Cold stamping die is at room temperature, the pressure through the use of equipment, the use of sheet metal dies so that the separation took placeinto a plastic deformation process. Processing object is a metallic or non-metallic sheet.
The design of stamping process analysis and die design for a given moldproducts, in comprehensive consideration of the stamping process of economy,parts processing products and complexity and accuracy factors on stamping process analysis and calculation, and put forward the reasonable process scheme and structure; finally, combined with the product of the process andthe existing processing method of rational design of progressive die layoutand processing method of saving time and material, reach the purpose of saving resources. This design introduced the mold design of nesting and feeding and discharging and guiding mode, the main pieces of determining clearance and edge size and blanking force calculation are discussed,and select the appropriate machine design, design of the main working parts of die size calculation and main parts and processing technology .
All in all, the production of Die efficient processing, low processing costs, material utilization high, the product of good consistency, the product quality is suit for the production needs, and easy to operate.
Key words：foreplate ,stamping,analysis of manufacturing ,modulus of continuity
